Bilstein G Series Shock Absorbers SKU Listing / Specs

Purchase	Part Number	Image View	Name	Detail Specs	UPC
Quantity	SKU: F4-BE3-A213-M0 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 11.38 Collapsed Length (MM): 289.0 Compression @0.26m/s: 740 Extended Length (IN): 17.19 Extended Length (MM): 436.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 450 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 2040	N/A
Quantity	SKU: F4-BE3-A213-M1 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 11.38 Collapsed Length (MM): 289.0 Compression @0.26m/s: 410 Extended Length (IN): 17.19 Extended Length (MM): 436.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 815 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 4020	N/A
Quantity	SKU: F4-BE3-A213-M2 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 11.38 Collapsed Length (MM): 289.0 Compression @0.26m/s: 335 Extended Length (IN): 17.19 Extended Length (MM): 436.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 745 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 3010	N/A
Quantity	SKU: F4-BE3-A213-M3 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 11.38 Collapsed Length (MM): 289.0 Compression @0.26m/s: 475 Extended Length (IN): 17.19 Extended Length (MM): 436.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 480 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 3030	N/A
Quantity	SKU: F4-BE3-A213-M4 CAD$ 237.17	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 11.38 Collapsed Length (MM): 289.0 Compression @0.26m/s: 730 Extended Length (IN): 17.19 Extended Length (MM): 436.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 895 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 4545	N/A
Quantity	SKU: F4-BE3-A213-M5 CAD$ 237.17	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 11.38 Collapsed Length (MM): 289.0 Compression @0.26m/s: 715 Extended Length (IN): 17.19 Extended Length (MM): 436.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 710 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 3535	N/A
Quantity	SKU: F4-BE3-A213-M6 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 11.38 Collapsed Length (MM): 289.0 Compression @0.26m/s: 920 Extended Length (IN): 17.19 Extended Length (MM): 436.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 1170 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 5555	N/A
Quantity	SKU: F4-BE3-A213-M7 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 11.38 Collapsed Length (MM): 289.0 Compression @0.26m/s: 730 Extended Length (IN): 17.19 Extended Length (MM): 436.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 315 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 1030	N/A
Quantity	SKU: F4-BE3-C230-H0 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 12.68 Collapsed Length (MM): 322.0 Compression @0.26m/s: 730 Extended Length (IN): 19.86 Extended Length (MM): 504.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 315 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 1030	N/A
Quantity	SKU: F4-BE3-C231-H1 CAD$ 228.59	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 12.68 Collapsed Length (MM): 322.0 Compression @0.26m/s: 670 Extended Length (IN): 19.86 Extended Length (MM): 504.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 865 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 1090	N/A
Quantity	SKU: F4-BE3-C232-H0 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 12.68 Collapsed Length (MM): 322.0 Compression @0.26m/s: 740 Extended Length (IN): 19.86 Extended Length (MM): 504.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 450 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 2040	N/A
Quantity	SKU: F4-BE3-C233-H0 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 12.68 Collapsed Length (MM): 322.0 Compression @0.26m/s: 475 Extended Length (IN): 19.86 Extended Length (MM): 504.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 480 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 3030	N/A
Quantity	SKU: F4-BE3-C234-H0 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 12.68 Collapsed Length (MM): 322.0 Compression @0.26m/s: 920 Extended Length (IN): 19.86 Extended Length (MM): 504.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 585 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 3050	N/A
Quantity	SKU: F4-BE3-C235-H0 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 12.68 Collapsed Length (MM): 322.0 Compression @0.26m/s: 1070 Extended Length (IN): 19.86 Extended Length (MM): 504.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 580 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 3060	N/A
Quantity	SKU: F4-BE3-C236-H0 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 12.68 Collapsed Length (MM): 322.0 Compression @0.26m/s: 715 Extended Length (IN): 19.86 Extended Length (MM): 504.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 710 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 3535	N/A
Quantity	SKU: F4-BE3-C237-H0 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 12.68 Collapsed Length (MM): 322.0 Compression @0.26m/s: 410 Extended Length (IN): 19.86 Extended Length (MM): 504.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 815 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 4020	N/A
Quantity	SKU: F4-BE3-C238-H0 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 12.68 Collapsed Length (MM): 322.0 Compression @0.26m/s: 730 Extended Length (IN): 19.86 Extended Length (MM): 504.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 895 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 4545	N/A
Quantity	SKU: F4-BE3-C239-H0 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 12.68 Collapsed Length (MM): 322.0 Compression @0.26m/s: 920 Extended Length (IN): 19.86 Extended Length (MM): 504.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 1170 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 5555	N/A
Quantity	SKU: F4-BE3-C240-H0 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 12.68 Collapsed Length (MM): 322.0 Compression @0.26m/s: 435 Extended Length (IN): 19.86 Extended Length (MM): 504.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 1505 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 6020	N/A
Quantity	SKU: F4-BE3-C241-H0 CAD$ 223.25	Enlarged View	Bilstein G Series Shock Absorbers SPECIAL ORDER SPECIAL ORDER (Estimated Ship Date: 4 - 8 Weeks) UpdatedOn: 4/24/2024 12:00:00 AM	Universal Fit Product. Body Diameter (ID): 36mm Boot Included: No Collapsed Length (IN): 12.68 Collapsed Length (MM): 322.0 Compression @0.26m/s: 1075 Extended Length (IN): 19.86 Extended Length (MM): 504.5 Internal Design: Monotube Lower Mount Type: 1/2in Heim Piston Type: Digressive Rebound @0.26m/s: 1380 Series: G Series Title: Bilstein Shock Absorbers Upper Mount Type: 1/2in Heim Valving Identifier: 6565	N/A

Bilstein G Series shock absorbers feature a steel monotube body with a 36mm piston designed for a variety of motorsports applications. These shock absorbers are available in 6 and 7 inch strokes with multiple valve setting options that provide optimal weight transfer and feel. They can also be converted to a coilover design (kit sold separately) for multiple platforms on dirt and asphalt. G Series shock absorbers are ideal for racers needing a lightweight high performance option with fade free handling and control.

Bilstein-pioneers of monotube gas shocks

Bilstein is the original manufacturer of monotube gas shocks and has improved upon the original design over the years. There's no doubt that Bilstein is the best monotube gas shock manufacturer at present.

There was a need to prevent hydraulic oil or damping fluid from foaming in conventional shock absorbers. The solution came in the form of a pressurized gas charge, comprising of nitrogen gas, separated from damping oil by a floating piston. This forms the basis of a monotube gas shock.

How Monotube Gas Shocks work?

As opposed to conventional twin tube shock absorbers that contain an outer fluid reservoir, monotube gas shocks do not contain an outer fluid tube. Instead, entire fluid is contained in the piston chamber, separated from high-pressure nitrogen gas charge by a floating piston. When piston moves down under the push of damping fluid, the gas charge gets compressed, creating an air spring effect within the shock absorber. This results in damping fluid being under constant pressure as it circulates through the valves in piston, leading to reduced foaming.

Benefits of Monotube Gas Shocks over Conventional Shock Absorbers

Various benefits of Monotube gas shock absorbers apart from reduced foaming can be summed up as:

Improved heat dissipation: Owing to repeated piston action, a lot of heat is produced in the piston chamber. In conventional twin tube shocks, outer tube restricts the heat loss from inner tube. In monotube gas shocks, there's better dissipation of heat and therefore, it runs cooler. It prevents thinning of damping fluid under the effect of heat and thus gives a more consistent performance.
Lighter body: Monotube gas shock is lighter than the corresponding conventional twin tube shock.
Multiple Mounting Positions: As there's no need to rely on gravity to move damping fluid through valves and into outer fluid reservoir, monotube gas shocks can be mounted in any position, even sideways for better aerodynamics.
Large piston diameter: As the piston floats and separates two sections, it has to be larger in diameter than a conventional twin tube with same external diameter. This increases shock sensitivity and allows it to be fine-tuned through adjustable valving to control overall car performance.

Special features of Bilstein gas shocks:

Bilstein gets all the better with time and manufactures state of the art gas shocks. Each Bilstein monotube damper is made of a polished stainless steel body, available in two variants:

without outer reservoir having defective disc valving and;
with outer reservoir having non-adjustable valving.

Popular Bilstein products available with Parts Engine include:

Bilstein B6 4600 Series Shock Absorbers
Bilstein B8 5100 Series Shock Absorbers
Bilstein B8 5160 Series Shock Absorbers with Reservoir
Bilstein B8 5125 Series Shock Absorbers
Bilstein B8 5165 Series Shock Absorbers with Reservoir.

Get the best and the latest Bilstein products for lowest prices at Parts Engine, along with free shipping anywhere in Canada.
